Description
| Features | Specifications |
| Model | FST-DC800V-30A |
| DC Voltage measurement | |
| DC Voltage Range | 180V-800V |
| Accuracy & resolution | ≤±0.5%, 0.01V |
| DC Voltage measurement | |
| Internal current range | 1-30A |
| Accuracy & resolution | ≤ ± 1% , 0.1A |
| Cell voltage Range | 0-15V |
| Accuracy & resolution | ≤ ± 0.5%, 0.01 V |
| AC POWER SUPPLY | |
| Power Supply | 220 Volts ± 10 %, 50 Hz+5 o, Single Phase AC |
| Cooling mode | Air Cooling |
| Communication & Storage | |
| Storage mode | Internal storage and External storage via Storage Card to PC software |
| Internal memory | 16Mbit Flash or Optional |
| Display | 7inch Touch screen |
| High-Voltage insulation test | Input-The enclosure：2200Vdc 1min
Input-Output：2200Vdc 1min Output- The enclosure：700Vdc 1min |
| Safety standard | EN610950 |
| CE Certificate | LVD: EN61010-12010; EMC:EN61326-1:2013 |
| Environment | |
| Work Temperature | -5～50℃ |
| Storage Temperature | -40～70℃ |
| Humidity | Relative humidity 5%～95% |
| Altitude | below 4000 m |
| Working Noise | <60dB |
| Net Weight(KG) | Around 35Kg |
